Stainless Steel 310 / 310S Pipe
High-Temperature Heat Resistant Stainless Steel Pipes
SS 310 Pipe is a high-chromium and nickel austenitic stainless steel designed for use in high-temperature corrosion-resistant applications. Grade 310S is the low-carbon version of 310, offering better weldability and preventing embrittlement in service. These pipes are capable of resisting oxidation up to 1100°C in mildly cyclic conditions, making them ideal for furnace parts and heat exchangers.
Technical Specifications
| Feature | Details |
|---|---|
| Standard | ASTM A312, A358, A213 |
| Grades | TP 310, 310S, 310H |
| Size | 1/2" NB to 24" NB |
| Schedules | SCH 5, 10S, 40S, 80S, 160, XXS |
| Length | Single Random, Double Random, Cut Length |
| Type | Seamless / Welded / ERW / Fabricated |
Mechanical Properties
| Property | Grade 310 | Grade 310S |
|---|---|---|
| Yield Strength (0.2% Offset) | Min 205 MPa | Min 205 MPa |
| Tensile Strength (Min) | 515 MPa | 515 MPa |
| Elongation (Min %) | 35 - 40% | 35 - 40% |
| Hardness (Brinell) | Max 225 HBW | Max 225 HBW |
Chemical Composition (%)
| Element | SS 310 | SS 310S |
|---|---|---|
| Carbon (C) | 0.25 max | 0.08 max |
| Manganese (Mn) | 2.00 max | 2.00 max |
| Chromium (Cr) | 24.0 - 26.0 | 24.0 - 26.0 |
| Nickel (Ni) | 19.0 - 22.0 | 19.0 - 22.0 |
| Silicon (Si) | 1.50 max | 1.50 max |
| Phosphorus (P) | 0.045 max | 0.045 max |
| Sulfur (S) | 0.030 max | 0.030 max |
| Nitrogen (N) | 0.10 max | 0.10 max |
Features and Benefits of SS 310 Pipe
- Outstanding oxidation resistance up to 1100°C (2010°F)
- High creep strength at elevated temperatures
- 310S variant reduces carbide precipitation during welding
- Good resistance to sulfidation and other forms of hot corrosion
- Excellent toughness and low magnetic permeability
- Superior performance in moderately carburizing atmospheres
- Versatile manufacturing in both seamless and large-diameter welded forms
- High resistance to thermal fatigue and cyclic heating
Applications & Uses
Furnace Parts
Used in burner tips, fire boxes, and kilns where high heat resistance is mandatory.
Heat Exchangers
Ideal for recuperators and high-temperature gas piping in industrial thermal plants.
Oil Refineries
Employed in fluid catalytic cracking units (FCCU) and hydro-processing systems.
